The V163-4.5 MW™, featuring a large rotor-size-to-rating ratio, helps you realise stable energy output and up to 10% more Annual Energy Production at park level under medium to low wind conditions.

V163-4.5 MW™ at a glance

The V163-4.5 MW™ is an evolutionary optimisation step based on the V150-4.2 MW™ and the V150-4.5 MW™ -  some of our most popular turbine models for medium and lower wind segments. Featuring an 18 percent increase in swept area, the V163-4.5 MW™ has a large rotor-size-to-rating ratio resulting in a higher capacity factor, leading to up to 10 percent higher Annual Energy Production at park level depending on site-specific conditions.

This increases power output at lower wind speeds significantly and improves predictability and stability in production, optimising the utilisation of the wind park as well as benefitting the energy grid.

4 MW

The Vestas 4 MW platform sets new standards for onshore wind performance within regimes ranging from very strong wind and typhoon conditions to ultra low wind.

IEC IIIB

The V163-4.5 MW™ is designed for medium and lower wind sites for optimised Annual Energy Production at park level.

+74 GW

The performance and versatility of the 4 MW platform has been proven with more than 74 GW installed in 59 countries since 2010.

Options
available for the
V163-4.5 MW™ IEC IIIB

  • Condition Monitoring System
  • Service Personnel Lift
  • Low Temperature Operation to -30°C
  • Fire Suppression
  • Vestas Shadow Flicker Control System
  • Vestas Bat Protection System
  • Nacelle Hatch for Air Inlet
  • Aviation Lights
  • Aviation Markings on the Blades

Technical specifications

POWER REGULATION OPERATIONAL DATA
Pitch regulated with variable speed
Rated power
4,500kW
Cut-in wind speed
3m/s
Cut-out wind speed
24m/s
Re cut-in wind speed
22m/s
Wind class
IEC S
Standard operating temperature range
from -30°C* to +45°C with de-rating above 27°C

SOUND POWER
Maximum
108.4/106.3 dB(A)*

 *with optional Serrated Trailing Edges


ROTOR
Rotor diameter
163m
Swept area
20,867m2
Aerodynamic brake
full blade feathering with 3 pitch cylinders

ELECTRICAL
Frequency
50/60 Hz
Converter
full scale

GEARBOX
Type
two planetary stages and one helical stage

TOWER
Hub heights
98 m (IEC S), 113 m (IEC S) and 126 m (IEC S)

NACELLE DIMENSIONS
Height for transport
3.5 m
Height installed (incl. CoolerTop®)
8.4 m
Length
12.96 m
Width
3.98 m

HUB DIMENSIONS
Max. transport height
3.5m
Max. transport width
4.0m
Max. transport length
5.5m

BLADE DIMENSIONS
Length
80.1m
Max. chord
4.3m
Max. weight per unit for transportation
70 metric tonnes

SUSTAINABILITY METRICS PENDING
Carbon footprint
4.7g CO2e/kWh
Return on energy break-even
5 months
Lifetime return on energy
45 times
Recyclability rate
83%

Configuration: 98m hub height, Vavg=7.9m/s, k=2.6. Depending on site-specific conditions. Metrics are based on an internal streamlined assessment. An externally reviewed Life Cycle Assessment will be made available on vestas.com once finalised.
